Semi automatic 8000A double sides spot welding cylindrical lithium battery pack welding machine
The Automatic Battery Pack Spot Welder is a general platform of automatic processing technology based on CNC, suitable battery pack spot welding and assembly in the factory. Compared with manual spot welding, the efficiency and accuracy of welding have been greatly improved. Humanized design makes the operation and debugging very easy and convenient.
There are two models of automatic spot welding machines:
ONT-800:Single Side Machine
ONT-700L:Double Side Machine
Please check table below for the difference of the two machines
| SPECIFICATIONS FOR ONT-800 AND ONT-700 |
| | ONT-800 | ONT-700L |
| Welding Head Number | 1 | 2 |
| Travel | X: 400mm;
Y: 500mm | X: 310mm;
Y: 600mm |
| Welding Spped | 0.5s/spot, 2000-2500pcs/h | 0.5s/spot, 3500-4000pcs/h |
| Welder Power Suppler | 5000A Inverter Spot Welder |
| Max Motor Speed | 1000mm/s |
| Max Battery Number | 450 pcs (18650) |
| Operate System | Embedded system |
| User Interface | Touch screen |
| Drive Mode | Step motor and precision guide rail |
| Power Supply | 220V/50Hz(machine); 3 phase, 380V/50Hz(Welder) |
| Air Pressure | 0.3-0.6 MPa |
| Machine Size | 800L*1500W*1650Hmm | 1980L*1150W*1930Hmm |
| Machine Weight | 300kg | 350kg |
Application Area:
With the corresponding fixture, ONT-700L can weld 18650, 21700,26650, 32650 and other cylindrical batteries and etc
Fixture/jigs can be customized accroding to customer battery PACK
Operation:
1. Setting the parameters of welding on the touch screen. (The same product only need to be set once)
2. Put the fixture with the battery pack on the quick clamping position.
3. Press the start button, ONT-700L automatically complete all welding actions.
4. ONT-700L sound to prompt operator replacement of new fixture (battery pack)
Our Company
Shenzhen Onetop Technology Co Ltd , is a manufacturer which combines R&D and marketing ,we have professional R&D team as well as proficient stuff ,and has been specializing in researching and producing high quality lithium battery machine for 10 years . Our main products ranges from 18650 battery pack assembly machine ,Power Battery PACK assembly machines ,Power Bank Assembly machine,Mobile Phone Battery assembly Machines,Battery safety test equipment,Injection molding machine,Molds, Molding materials, machine parts, etc
We keep in place with the word ,we adopt lastest technology and design ,our Onetop series battery machine stands out in the same industry area ,they are of national advanced technologycal level and have been identified by experts from Shenzhen Science & Technology and Information Bureau .Up to now ,we have obtained many inventions patents ,practical new patents ,and own independent intellectual property rights
.
With the increasing development ,We have created two workshops to manufacture battery machines and injection molding machines
Through our efforts, the Automatic Battery PACK Assembly machines are now widely used in Mobile phone,Power bank,Laptop,Electric bikes,Electric vehicle,solar street lights,Solar energy storage,Banks,LED devices,Health Equipments ect,the low-pressure injection molding machines are now widely used in PCBs, sensor products, wiring harnesses, medical electronic products, etc. In addition, OEM/ODM services can be provided to customers worldwide. Our products enjoy high quality and guarantee all-weather after-sales service, thus winning our 70% market share.we look forward to cooperation with the customers all over the world .
Our Main product
1. Automatic Battery PACK Assembly Line
2. Power Battery PACK machines
3. Power Bank Assembly Line
4. Battery safe test machine
5. Injection Molding Machine
Cooperation customer
In China: Like BYD,SCUD, Desay, UTEK, LISHEN, GREAT POWER,TIANNENG Battery, SUMEC.etc.
In India, like INTEX,ICCON, OKAYA,LIVGUARD, AXIOM, Fusion Power, PurEnergy,Autonix ect
In US: Like Holley, MSD,Lithium battery power ect
Others country customers, like Germany Varta, Austria Kreisel Electric,Turkey Imecar Elektronik ,Korea Weltop,Chience,PowerCraft, VIBEON ect
Packing and shipping
*Be Packed by Wooden Box
*Lead Time: Standard Machine: 7-10 working days
*Customized Machine: 30-35 days
Our Service
● Pre-sales
1) Inquiry and consulting support. All will be replied in 12 hours.
2) View our Factory and testing the machine, demonstrate how the machine work.
● After-Sales
1) Training how to install the machine, training how to use the machine.
2) Engineers available to service machinery overseas
3) 1-year guarantee ( free maintain in a year)
4) Replacement parts and other accessories provided
